6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header).

2 x USB 3.2 Gen 1 ports available through the internal USB header.

4 x USB 3.2 Gen 1 ports on the back panel.

Support for RAID 0, RAID 1, and RAID 10.

3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDsġ x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs:Ĥ x SATA 6Gb/s connectors, integrated in the Chipset:.

3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs.

* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.ġ x PCI Express x16 slot (PCIEX4), integrated in the Chipset:ġ x PCI Express x1 slot (PCIEX1), integrated in the Chipset:ġ x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:

3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support PCIe 3.0 x16 mode.

3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode.

Realtek ® GbE LAN chip (1000 Mbit/100 Mbit)ġ x PCI Express x16 slot (PCIEX16), integrated in the CPU:

Please visit GIGABYTE’s website for details on configuring the audio software.

* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. * Support for HDMI 2.1 version, HDCP 2.3, and HDR. 1 x HDMI port, supporting a maximum resolution of 4096× Hz.* The DVI-D port does not support D-Sub connection by adapter. 1 x DVI-D port, supporting a maximum resolution of 1920× Hz.Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors: (Please refer “Memory Support List” for more information.) Support for Extreme Memory Profile (XMP) memory modules.Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules.Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules.3rd Gen AMD Ryzen™ with Radeon™ Graphics processors:.AMD Ryzen™ 5000 series processors/ 3rd Generation AMD Ryzen™ :.4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory.

(Please refer “CPU Support List” for more information.) AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ and 3rd Gen Ryzen™ with Radeon™ Graphics Processors.
